Kuzma Stabi XL DC
Kuzma Stabi XL DC
Turntable
Kuzma Stabi XLDC
Stabi XL DC differs from previous Stabi XL, XL2 & XL4 turntables by using a very special DC motor, a machined plastic belt and a new power supply (PS DC), which gives a new, unique and uniformly precise drive to the platter.
New platter drive lifts this turntable's performance to a new level.
A heavy brass and acrylic reflex action clamp provides additional damping of the vibration created by playback, as well as flattening warped records. The record is pressed securely to the platter mat, which is a semi-hard combination of rubber and textile.
The tonearm tower is a massive brass unit and the armboard can be exchanged to accommodate various tonearms. The mass of the tower gives structural and damping rigidity to the tonearm.
The optional VTA tower allows for VTA adjustment during normal use without loss of rigidity or azimuth. The movable part is supported via a linear ball bearing 30mm in diameter and 100mm in length which gives firm support while allowing VTA to be changed. Adjustments can be made in a range of 80mm, each turn of the knob representing 0.1mm precisely. A digital micrometer gives a readout in the range of 12mm at an exactitude of 0.01mm. These adjustments are repeatable. Additionally, a lever on the side of the tower allows for three basic positions, normal, a setting for thin records and higher for thicker records of 180 grams.
Technical Data:
Tonearm Tower: 14 kg
Speeds: 33, 45, 78 rpm
Dimension: 450 x 400 x 300mm
Power Supply: 110 V - 240 V, 50/60 Hz
Mass (total w/o ps): 80 kg
Platter: 22 kg
Base: 27 kg
Motor Tower: 7.5 kg
